Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPT |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPQ MR0400 |
R 1/8 |
4 |
|
| RPQ MR0401 |
R 1/4 |
4 |
|
| RPQ MR0500 |
R 1/8 |
5 |
|
| RPQ MR0501 |
R 1/4 |
5 |
|
| RPQ MR0502 |
R 3/8 |
5 |
|
| RPQ MR0503 |
R 1/2 |
5 |
|
| RPQ MR0600 |
R 1/8 |
6 |
|
| RPQ MR0601 |
R 1/4 |
6 |
|
| RPQ MR0602 |
R 3/8 |
6 |
|
| RPQ MR0603 |
R 1/2 |
6 |
|
| RPQ MR0800 |
R 1/8 |
8 |
|
| RPQ MR0801 |
R 1/4 |
8 |
|
| RPQ MR0802 |
R 3/8 |
8 |
|
| RPQ MR0803 |
R 1/2 |
8 |
|
| RPQ MR1000 |
R 1/8 |
10 |
|
| RPQ MR1001 |
R 1/4 |
10 |
|
| RPQ MR1002 |
R 3/8 |
10 |
|
| RPQ MR1003 |
R 1/2 |
10 |
|
| RPQ MR1201 |
R 1/4 |
12 |
|
| RPQ MR1202 |
R 3/8 |
12 |
|
| RPQ MR1203 |
R 1/2 |
12 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
E mm |
| RPQ MR0400 |
39.4 |
14.5 |
10 |
31.9 |
10 |
| RPQ MR0401 |
40.9 |
14.5 |
14 |
31.9 |
10 |
| RPQ MR0500 |
43 |
16.5 |
12 |
35.5 |
12.8 |
| RPQ MR0501 |
44.5 |
16.5 |
14 |
35.5 |
12.8 |
| RPQ MR0502 |
47 |
16.5 |
17 |
36 |
12.8 |
| RPQ MR0503 |
49.5 |
16.5 |
21 |
36.5 |
12.8 |
| RPQ MR0600 |
43 |
16.5 |
12 |
35.5 |
12.8 |
| RPQ MR0601 |
44.5 |
16.5 |
14 |
35.5 |
12.8 |
| RPQ MR0602 |
47 |
16.5 |
17 |
36 |
12.8 |
| RPQ MR0603 |
49.5 |
16.5 |
21 |
36.5 |
12.8 |
| RPQ MR0800 |
46 |
19 |
14 |
38.5 |
13.8 |
| RPQ MR0801 |
47.5 |
19 |
14 |
38.5 |
13.8 |
| RPQ MR0802 |
50 |
19 |
17 |
39 |
13.8 |
| RPQ MR0803 |
52.5 |
19 |
21 |
39.5 |
13.8 |
| RPQ MR1000 |
51.3 |
22 |
17 |
43.8 |
16.8 |
| RPQ MR1001 |
52.8 |
22 |
17 |
43.8 |
16.8 |
| RPQ MR1002 |
54.8 |
22 |
17 |
43.8 |
16.8 |
| RPQ MR1003 |
57.3 |
22 |
21 |
44.3 |
16.8 |
| RPQ MR1201 |
55.5 |
23 |
19 |
46.5 |
19.8 |
| RPQ MR1202 |
58 |
23 |
19 |
47 |
19.8 |
| RPQ MR1203 |
60 |
23 |
21 |
47 |
19.8 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
