Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPP |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPQ MG0400 |
G 1/8 |
4 |
|
| RPQ MG0401 |
G 1/4 |
4 |
|
| RPQ MG0500 |
G 1/8 |
5 |
|
| RPQ MG0501 |
G 1/4 |
5 |
|
| RPQ MG0502 |
G 3/8 |
5 |
|
| RPQ MG0503 |
G 1/2 |
5 |
|
| RPQ MG0600 |
G 1/8 |
6 |
|
| RPQ MG0601 |
G 1/4 |
6 |
|
| RPQ MG0602 |
G 3/8 |
6 |
|
| RPQ MG0603 |
G 1/2 |
6 |
|
| RPQ MG0800 |
G 1/8 |
8 |
|
| RPQ MG0801 |
G 1/4 |
8 |
|
| RPQ MG0802 |
G 3/8 |
8 |
|
| RPQ MG0803 |
G 1/2 |
8 |
|
| RPQ MG1000 |
G 1/8 |
10 |
|
| RPQ MG1001 |
G 1/4 |
10 |
|
| RPQ MG1002 |
G 3/8 |
10 |
|
| RPQ MG1003 |
G 1/2 |
10 |
|
| RPQ MG1201 |
G 1/4 |
12 |
|
| RPQ MG1202 |
G 3/8 |
12 |
|
| RPQ MG1203 |
G 1/2 |
12 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
E mm |
| RPQ MG0400 |
38 |
14.5 |
12 |
33.5 |
10 |
| RPQ MG0401 |
39 |
14.5 |
14 |
33 |
10 |
| RPQ MG0500 |
41.5 |
16.5 |
12 |
35.5 |
12.8 |
| RPQ MG0501 |
42.5 |
16.5 |
14 |
36.5 |
12.8 |
| RPQ MG0502 |
44 |
16.5 |
17 |
37.5 |
12.8 |
| RPQ MG0503 |
44 |
16.5 |
21 |
36 |
12.8 |
| RPQ MG0600 |
42 |
16.5 |
12 |
35.5 |
12.8 |
| RPQ MG0601 |
43 |
16.5 |
14 |
37 |
12.8 |
| RPQ MG0602 |
44 |
16.5 |
17 |
37.5 |
12.8 |
| RPQ MG0603 |
45 |
16.5 |
21 |
37 |
12.8 |
| RPQ MG0800 |
46 |
19 |
14 |
40.5 |
13.8 |
| RPQ MG0801 |
46 |
19 |
14 |
40 |
13.8 |
| RPQ MG0802 |
47 |
19 |
17 |
40 |
13.8 |
| RPQ MG0803 |
48.5 |
19 |
21 |
40.5 |
13.8 |
| RPQ MG1000 |
51 |
22 |
17 |
45 |
16.8 |
| RPQ MG1001 |
51 |
22 |
17 |
45 |
16.8 |
| RPQ MG1002 |
51 |
22 |
17 |
44.5 |
16.8 |
| RPQ MG1003 |
52 |
22 |
21 |
44 |
16.8 |
| RPQ MG1201 |
55 |
23 |
19 |
49 |
19.8 |
| RPQ MG1202 |
55 |
23 |
19 |
48.5 |
19.8 |
| RPQ MG1203 |
56 |
23 |
21 |
48 |
19.8 |
AG BSPT
R 1/8
Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPT |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPD MR0400 |
R 1/8 |
4 |
|
| RPD MR0401 |
R 1/4 |
4 |
|
| RPD MR0500 |
R 1/8 |
5 |
|
| RPD MR0501 |
R 1/4 |
5 |
|
| RPD MR0502 |
R 3/8 |
5 |
|
| RPD MR0503 |
R 1/2 |
5 |
|
| RPD MR0600 |
R 1/8 |
6 |
|
| RPD MR0601 |
R 1/4 |
6 |
|
| RPD MR0602 |
R 3/8 |
6 |
|
| RPD MR0603 |
R 1/2 |
6 |
|
| RPD MR0800 |
R 1/8 |
8 |
|
| RPD MR0801 |
R 1/4 |
8 |
|
| RPD MR0802 |
R 3/8 |
8 |
|
| RPD MR0803 |
R 1/2 |
8 |
|
| RPD MR1000 |
R 1/8 |
10 |
|
| RPD MR1001 |
R 1/4 |
10 |
|
| RPD MR1002 |
R 3/8 |
10 |
|
| RPD MR1003 |
R 1/2 |
10 |
|
| RPD MR1201 |
R 1/4 |
12 |
|
| RPD MR1202 |
R 3/8 |
12 |
|
| RPD MR1203 |
R 1/2 |
12 |
|
| RPD MR1402 |
R 3/8 |
14 |
|
| RPD MR1403 |
R 1/2 |
14 |
|
| RPD MR1602 |
R 3/8 |
16 |
|
| RPD MR1603 |
R 1/2 |
16 |
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
| RPD MR0400 |
21 |
11.5 |
10 |
13.5 |
| RPD MR0401 |
20 |
16 |
14 |
11 |
| RPD MR0500 |
22 |
14 |
12 |
14.5 |
| RPD MR0501 |
21 |
16 |
14 |
12 |
| RPD MR0502 |
23 |
19.5 |
17 |
12 |
| RPD MR0503 |
25.5 |
24 |
21 |
12.5 |
| RPD MR0600 |
22 |
14 |
12 |
14.5 |
| RPD MR0601 |
21 |
16 |
14 |
12 |
| RPD MR0602 |
23 |
19.5 |
17 |
12 |
| RPD MR0603 |
25.5 |
24 |
21 |
12.5 |
| RPD MR0800 |
27 |
16 |
14 |
19.5 |
| RPD MR0801 |
24 |
16 |
14 |
15 |
| RPD MR0802 |
24.5 |
19.5 |
17 |
13.5 |
| RPD MR0803 |
26 |
24 |
21 |
13 |
| RPD MR1000 |
28 |
19.5 |
17 |
20.5 |
| RPD MR1001 |
29 |
19.5 |
17 |
20 |
| RPD MR1002 |
27 |
19.5 |
17 |
16 |
| RPD MR1003 |
26 |
24 |
21 |
13 |
| RPD MR1201 |
33 |
22 |
19 |
24 |
| RPD MR1202 |
29.5 |
22 |
19 |
18.5 |
| RPD MR1203 |
27.5 |
24 |
21 |
8 |
| RPD MR1402 |
33.1 |
25 |
22 |
22.1 |
| RPD MR1403 |
31.2 |
25 |
22 |
18.2 |
| RPD MR1602 |
35 |
27.5 |
24 |
24 |
| RPD MR1603 |
33 |
27.5 |
24 |
20 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
