Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
IG BSPP |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPD FG0400 |
G 1/8 |
4 |
|
| RPD FG0401 |
G 1/4 |
4 |
|
| RPD FG0500 |
G 1/8 |
5 |
|
| RPD FG0501 |
G 1/4 |
5 |
|
| RPD FG0502 |
G 3/8 |
5 |
|
| RPD FG0503 |
G 1/2 |
5 |
|
| RPD FG0600 |
G 1/8 |
6 |
|
| RPD FG0601 |
G 1/4 |
6 |
|
| RPD FG0602 |
G 3/8 |
6 |
|
| RPD FG0603 |
G 1/2 |
6 |
|
| RPD FG0800 |
G 1/8 |
8 |
|
| RPD FG0801 |
G 1/4 |
8 |
|
| RPD FG0802 |
G 3/8 |
8 |
|
| RPD FG0803 |
G 1/2 |
8 |
|
| RPD FG1000 |
G 1/8 |
10 |
|
| RPD FG1001 |
G 1/4 |
10 |
|
| RPD FG1002 |
G 3/8 |
10 |
|
| RPD FG1003 |
G 1/2 |
10 |
|
| RPD FG1201 |
G 1/4 |
12 |
|
| RPD FG1202 |
G 3/8 |
12 |
|
| RPD FG1203 |
G 1/2 |
12 |
|
| RPD FG1402 |
G 3/8 |
14 |
|
| RPD FG1403 |
G 1/2 |
14 |
|
| RPD FG1602 |
G 3/8 |
16 |
|
| RPD FG1603 |
G 1/2 |
16 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
| RPD FG0400 |
24 |
16.5 |
14 |
14 |
| RPD FG0401 |
26.5 |
20 |
17 |
19 |
| RPD FG0500 |
27 |
16.5 |
14 |
20 |
| RPD FG0501 |
26 |
20 |
17 |
18.5 |
| RPD FG0502 |
28.5 |
22 |
19 |
20.5 |
| RPD FG0503 |
31 |
28 |
24 |
21 |
| RPD FG0600 |
27 |
16.5 |
14 |
20 |
| RPD FG0601 |
26 |
20 |
17 |
18.5 |
| RPD FG0602 |
28.5 |
22 |
19 |
20.5 |
| RPD FG0603 |
31 |
28 |
24 |
21 |
| RPD FG0800 |
28 |
20 |
17 |
21 |
| RPD FG0801 |
28 |
20 |
17 |
20.5 |
| RPD FG0802 |
28.5 |
22 |
19 |
20.5 |
| RPD FG0803 |
31 |
28 |
24 |
21 |
| RPD FG1000 |
29.5 |
22 |
19 |
22.5 |
| RPD FG1001 |
29.5 |
22 |
19 |
22 |
| RPD FG1002 |
32 |
24.5 |
21 |
24 |
| RPD FG1003 |
32 |
28 |
24 |
22 |
| RPD FG1201 |
31.5 |
24.5 |
21 |
24 |
| RPD FG1202 |
33 |
24.5 |
21 |
25 |
| RPD FG1203 |
33 |
28 |
24 |
23 |
| RPD FG1402 |
31.3 |
28 |
24 |
23.3 |
| RPD FG1403 |
32 |
28 |
24 |
22 |
| RPD FG1602 |
34 |
28 |
24 |
26 |
| RPD FG1603 |
35 |
28 |
24 |
25 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
