Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPP |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPD MG0400 |
G 1/8 |
4 |
|
| RPD MG0401 |
G 1/4 |
4 |
|
| RPD MG0500 |
G 1/8 |
5 |
|
| RPD MG0501 |
G 1/4 |
5 |
|
| RPD MG0502 |
G 3/8 |
5 |
|
| RPD MG0503 |
G 1/2 |
5 |
|
| RPD MG0600 |
G 1/8 |
6 |
|
| RPD MG0601 |
G 1/4 |
6 |
|
| RPD MG0602 |
G 3/8 |
6 |
|
| RPD MG0603 |
G 1/2 |
6 |
|
| RPD MG0800 |
G 1/8 |
8 |
|
| RPD MG0801 |
G 1/4 |
8 |
|
| RPD MG0802 |
G 3/8 |
8 |
|
| RPD MG0803 |
G 1/2 |
8 |
|
| RPD MG1000 |
G 1/8 |
10 |
|
| RPD MG1001 |
G 1/4 |
10 |
|
| RPD MG1002 |
G 3/8 |
10 |
|
| RPD MG1003 |
G 1/2 |
10 |
|
| RPD MG1201 |
G 1/4 |
12 |
|
| RPD MG1202 |
G 3/8 |
12 |
|
| RPD MG1203 |
G 1/2 |
12 |
|
| RPD MG1402 |
G 3/8 |
14 |
|
| RPD MG1403 |
G 1/2 |
14 |
|
| RPD MG1602 |
G 3/8 |
16 |
|
| RPD MG1603 |
G 1/2 |
16 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
| RPD MG0400 |
20 |
14 |
12 |
14.5 |
| RPD MG0401 |
19 |
16.5 |
14 |
13 |
| RPD MG0500 |
24 |
14 |
12 |
18.5 |
| RPD MG0501 |
21 |
16.5 |
14 |
15 |
| RPD MG0502 |
21 |
20 |
17 |
14.5 |
| RPD MG0503 |
22.5 |
22 |
19 |
14.5 |
| RPD MG0600 |
24 |
14 |
12 |
18.5 |
| RPD MG0601 |
21 |
16.5 |
14 |
15 |
| RPD MG0602 |
21 |
20 |
17 |
20.5 |
| RPD MG0603 |
22.5 |
22 |
19 |
14.5 |
| RPD MG0800 |
25.5 |
16.5 |
14 |
20 |
| RPD MG0801 |
22 |
16.5 |
14 |
16 |
| RPD MG0802 |
21 |
20 |
17 |
14.5 |
| RPD MG0803 |
22.5 |
22 |
19 |
14.5 |
| RPD MG1000 |
27.8 |
20 |
17 |
22.3 |
| RPD MG1001 |
27.8 |
20 |
17 |
21.8 |
| RPD MG1002 |
25.8 |
22 |
19 |
19.3 |
| RPD MG1003 |
26.3 |
25 |
21 |
18.3 |
| RPD MG1201 |
30 |
22 |
19 |
24 |
| RPD MG1202 |
26.5 |
22 |
19 |
20 |
| RPD MG1203 |
28 |
25 |
21 |
20 |
| RPD MG1402 |
30.8 |
25.5 |
22 |
24.3 |
| RPD MG1403 |
28 |
28 |
24 |
20 |
| RPD MG1602 |
33 |
28 |
24 |
26.5 |
| RPD MG1603 |
34.5 |
28 |
24 |
26.5 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
