Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPT |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPT CR0400 |
R 1/8 |
4 |
|
| RPT CR0401 |
R 1/4 |
4 |
|
| RPT CR0500 |
R 1/8 |
5 |
|
| RPT CR0501 |
R 1/4 |
5 |
|
| RPT CR0502 |
R 3/8 |
5 |
|
| RPT CR0503 |
R 1/2 |
5 |
|
| RPT CR0600 |
R 1/8 |
6 |
|
| RPT CR0601 |
R 1/4 |
6 |
|
| RPT CR0602 |
R 3/8 |
6 |
|
| RPT CR0603 |
R 1/2 |
6 |
|
| RPT CR0800 |
R 1/8 |
8 |
|
| RPT CR0801 |
R 1/4 |
8 |
|
| RPT CR0802 |
R 3/8 |
8 |
|
| RPT CR0803 |
R 1/2 |
8 |
|
| RPT CR1000 |
R 1/8 |
10 |
|
| RPT CR1001 |
R 1/4 |
10 |
|
| RPT CR1002 |
R 3/8 |
10 |
|
| RPT CR1003 |
R 1/2 |
10 |
|
| RPT CR1201 |
R 1/4 |
12 |
|
| RPT CR1202 |
R 3/8 |
12 |
|
| RPT CR1203 |
R 1/2 |
12 |
|
| RPT CR1402 |
R 3/8 |
14 |
|
| RPT CR1403 |
R 1/2 |
14 |
|
| RPT CR1602 |
R 3/8 |
16 |
|
| RPT CR1603 |
R 1/2 |
16 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
E mm |
| RPT CR0400 |
35 |
25 |
10 |
17.5 |
10 |
| RPT CR0401 |
35 |
26.5 |
14 |
17.5 |
10 |
| RPT CR0500 |
41 |
27.5 |
12 |
20 |
12.8 |
| RPT CR0501 |
41 |
29 |
14 |
20 |
12.8 |
| RPT CR0502 |
41 |
31.5 |
17 |
20.5 |
12.8 |
| RPT CR0503 |
41 |
34 |
21 |
21 |
12.8 |
| RPT CR0600 |
41 |
27.5 |
12 |
20 |
12.8 |
| RPT CR0601 |
41 |
29 |
14 |
20 |
12.8 |
| RPT CR0602 |
41 |
31.5 |
17 |
20.5 |
12.8 |
| RPT CR0603 |
41 |
34 |
21 |
21 |
12.8 |
| RPT CR0800 |
45 |
29.5 |
14 |
22 |
13.8 |
| RPT CR0801 |
45 |
31 |
14 |
22 |
13.8 |
| RPT CR0802 |
45 |
33.5 |
17 |
22.5 |
13.8 |
| RPT CR0803 |
45 |
36 |
21 |
23 |
13.8 |
| RPT CR1000 |
52.6 |
33.2 |
17 |
25.7 |
16.8 |
| RPT CR1001 |
52.6 |
34.7 |
17 |
25.7 |
16.8 |
| RPT CR1002 |
52.6 |
36.7 |
17 |
25.7 |
16.8 |
| RPT CR1003 |
52.6 |
39.2 |
21 |
26.2 |
16.8 |
| RPT CR1201 |
55.6 |
35.5 |
19 |
26.5 |
19.8 |
| RPT CR1202 |
55.6 |
38 |
19 |
27 |
19.8 |
| RPT CR1203 |
55.6 |
40 |
21 |
27 |
19.8 |
| RPT CR1402 |
62 |
41.2 |
22 |
30.2 |
22.7 |
| RPT CR1403 |
62 |
43.2 |
22 |
30.2 |
22.7 |
| RPT CR1602 |
64.6 |
43 |
24 |
32 |
23.8 |
| RPT CR1603 |
64.6 |
45 |
24 |
32 |
23.8 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
