Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPT |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPT AR0400 |
R 1/8 |
4 |
|
| RPT AR0401 |
R 1/4 |
4 |
|
| RPT AR0500 |
R 1/8 |
5 |
|
| RPT AR0501 |
R 1/4 |
5 |
|
| RPT AR0502 |
R 3/8 |
5 |
|
| RPT AR0503 |
R 1/2 |
5 |
|
| RPT AR0600 |
R 1/8 |
6 |
|
| RPT AR0601 |
R 1/4 |
6 |
|
| RPT AR0602 |
R 3/8 |
6 |
|
| RPT AR0603 |
R 1/2 |
6 |
|
| RPT AR0800 |
R 1/8 |
8 |
|
| RPT AR0801 |
R 1/4 |
8 |
|
| RPT AR0802 |
R 3/8 |
8 |
|
| RPT AR0803 |
R 1/2 |
8 |
|
| RPT AR1000 |
R 1/8 |
10 |
|
| RPT AR1001 |
R 1/4 |
10 |
|
| RPT AR1002 |
R 3/8 |
10 |
|
| RPT AR1003 |
R 1/2 |
10 |
|
| RPT AR1201 |
R 1/4 |
12 |
|
| RPT AR1202 |
R 3/8 |
12 |
|
| RPT AR1203 |
R 1/2 |
12 |
|
| RPT AR1402 |
R 3/8 |
14 |
|
| RPT AR1403 |
R 1/2 |
14 |
|
| RPT AR1602 |
R 3/8 |
16 |
|
| RPT AR1603 |
R 1/2 |
16 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
E mm |
| RPT AR0400 |
42.5 |
17.5 |
10 |
35 |
10 |
| RPT AR0401 |
44 |
17.5 |
14 |
35 |
10 |
| RPT AR0500 |
48 |
20.5 |
12 |
40.5 |
12.8 |
| RPT AR0501 |
49.5 |
20.5 |
14 |
40.5 |
12.8 |
| RPT AR0502 |
52 |
20.5 |
17 |
41 |
12.8 |
| RPT AR0503 |
54.5 |
20.5 |
21 |
41.5 |
12.8 |
| RPT AR0600 |
48 |
20.5 |
12 |
40.5 |
12.8 |
| RPT AR0601 |
49.5 |
20.5 |
14 |
40.5 |
12.8 |
| RPT AR0602 |
52 |
20.5 |
17 |
41 |
12.8 |
| RPT AR0603 |
54.5 |
20.5 |
21 |
41.5 |
12.8 |
| RPT AR0800 |
52 |
22.5 |
14 |
44.5 |
13.8 |
| RPT AR0801 |
53.5 |
22.5 |
14 |
44.5 |
13.8 |
| RPT AR0802 |
56 |
22.5 |
17 |
45 |
13.8 |
| RPT AR0803 |
58.5 |
22.5 |
21 |
45.5 |
13.8 |
| RPT AR1000 |
59.5 |
26.3 |
17 |
52 |
16.8 |
| RPT AR1001 |
61 |
26.3 |
17 |
52 |
16.8 |
| RPT AR1002 |
63 |
26.3 |
17 |
52 |
16.8 |
| RPT AR1003 |
65.5 |
26.3 |
21 |
52.5 |
16.8 |
| RPT AR1201 |
63.3 |
27.8 |
19 |
54.3 |
19.8 |
| RPT AR1202 |
65.8 |
27.8 |
19 |
54.8 |
19.8 |
| RPT AR1203 |
67.8 |
27.8 |
21 |
54.8 |
19.8 |
| RPT AR1402 |
72.2 |
31 |
22 |
61.2 |
22.7 |
| RPT AR1403 |
74.2 |
31 |
22 |
61.2 |
22.7 |
| RPT AR1602 |
75.3 |
32.3 |
24 |
64.3 |
23.8 |
| RPT AR1603 |
77.3 |
32.3 |
24 |
64.3 |
23.8 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
