Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPT |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPD MR0400 |
R 1/8 |
4 |
|
| RPD MR0401 |
R 1/4 |
4 |
|
| RPD MR0500 |
R 1/8 |
5 |
|
| RPD MR0501 |
R 1/4 |
5 |
|
| RPD MR0502 |
R 3/8 |
5 |
|
| RPD MR0503 |
R 1/2 |
5 |
|
| RPD MR0600 |
R 1/8 |
6 |
|
| RPD MR0601 |
R 1/4 |
6 |
|
| RPD MR0602 |
R 3/8 |
6 |
|
| RPD MR0603 |
R 1/2 |
6 |
|
| RPD MR0800 |
R 1/8 |
8 |
|
| RPD MR0801 |
R 1/4 |
8 |
|
| RPD MR0802 |
R 3/8 |
8 |
|
| RPD MR0803 |
R 1/2 |
8 |
|
| RPD MR1000 |
R 1/8 |
10 |
|
| RPD MR1001 |
R 1/4 |
10 |
|
| RPD MR1002 |
R 3/8 |
10 |
|
| RPD MR1003 |
R 1/2 |
10 |
|
| RPD MR1201 |
R 1/4 |
12 |
|
| RPD MR1202 |
R 3/8 |
12 |
|
| RPD MR1203 |
R 1/2 |
12 |
|
| RPD MR1402 |
R 3/8 |
14 |
|
| RPD MR1403 |
R 1/2 |
14 |
|
| RPD MR1602 |
R 3/8 |
16 |
|
| RPD MR1603 |
R 1/2 |
16 |
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
| RPD MR0400 |
21 |
11.5 |
10 |
13.5 |
| RPD MR0401 |
20 |
16 |
14 |
11 |
| RPD MR0500 |
22 |
14 |
12 |
14.5 |
| RPD MR0501 |
21 |
16 |
14 |
12 |
| RPD MR0502 |
23 |
19.5 |
17 |
12 |
| RPD MR0503 |
25.5 |
24 |
21 |
12.5 |
| RPD MR0600 |
22 |
14 |
12 |
14.5 |
| RPD MR0601 |
21 |
16 |
14 |
12 |
| RPD MR0602 |
23 |
19.5 |
17 |
12 |
| RPD MR0603 |
25.5 |
24 |
21 |
12.5 |
| RPD MR0800 |
27 |
16 |
14 |
19.5 |
| RPD MR0801 |
24 |
16 |
14 |
15 |
| RPD MR0802 |
24.5 |
19.5 |
17 |
13.5 |
| RPD MR0803 |
26 |
24 |
21 |
13 |
| RPD MR1000 |
28 |
19.5 |
17 |
20.5 |
| RPD MR1001 |
29 |
19.5 |
17 |
20 |
| RPD MR1002 |
27 |
19.5 |
17 |
16 |
| RPD MR1003 |
26 |
24 |
21 |
13 |
| RPD MR1201 |
33 |
22 |
19 |
24 |
| RPD MR1202 |
29.5 |
22 |
19 |
18.5 |
| RPD MR1203 |
27.5 |
24 |
21 |
8 |
| RPD MR1402 |
33.1 |
25 |
22 |
22.1 |
| RPD MR1403 |
31.2 |
25 |
22 |
18.2 |
| RPD MR1602 |
35 |
27.5 |
24 |
24 |
| RPD MR1603 |
33 |
27.5 |
24 |
20 |
