Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPT |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPB MR0400 |
R 1/8 |
4 |
|
| RPB MR0401 |
R 1/4 |
4 |
|
| RPB MR0500 |
R 1/8 |
5 |
|
| RPB MR0501 |
R 1/4 |
5 |
|
| RPB MR0502 |
R 3/8 |
5 |
|
| RPB MR0503 |
R 1/2 |
5 |
|
| RPB MR0600 |
R 1/8 |
6 |
|
| RPB MR0601 |
R 1/4 |
6 |
|
| RPB MR0602 |
R 3/8 |
6 |
|
| RPB MR0603 |
R 1/2 |
6 |
|
| RPB MR0800 |
R 1/8 |
8 |
|
| RPB MR0801 |
R 1/4 |
8 |
|
| RPB MR0802 |
R 3/8 |
8 |
|
| RPB MR0803 |
R 1/2 |
8 |
|
| RPB MR1000 |
R 1/8 |
10 |
|
| RPB MR1001 |
R 1/4 |
10 |
|
| RPB MR1002 |
R 3/8 |
10 |
|
| RPB MR1003 |
R 1/2 |
10 |
|
| RPB MR1201 |
R 1/4 |
12 |
|
| RPB MR1202 |
R 3/8 |
12 |
|
| RPB MR1203 |
R 1/2 |
12 |
|
| RPB MR1602 |
R 3/8 |
16 |
|
| RPB MR1603 |
R 1/2 |
16 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
E mm |
| RPB MR0400 |
25 |
21.8 |
10 |
17.5 |
10 |
| RPB MR0401 |
29 |
24 |
14 |
20 |
10 |
| RPB MR0500 |
25 |
23 |
10 |
17.5 |
12.8 |
| RPB MR0501 |
29 |
25.5 |
14 |
20 |
12.8 |
| RPB MR0502 |
35 |
27.1 |
19 |
24 |
12.8 |
| RPB MR0503 |
40 |
30.1 |
24 |
27 |
12.8 |
| RPB MR0600 |
25 |
23 |
10 |
17.5 |
12.8 |
| RPB MR0601 |
29 |
25.5 |
14 |
20 |
12.8 |
| RPB MR0602 |
35 |
27.1 |
19 |
24 |
12.8 |
| RPB MR0603 |
40 |
30.1 |
24 |
27 |
12.8 |
| RPB MR0800 |
25 |
24.6 |
10 |
17.5 |
13.8 |
| RPB MR0801 |
29 |
26.8 |
14 |
20 |
13.8 |
| RPB MR0802 |
35 |
28.8 |
19 |
24 |
13.8 |
| RPB MR0803 |
40 |
30.5 |
24 |
27 |
13.8 |
| RPB MR1000 |
25 |
28.5 |
10 |
17.5 |
16.8 |
| RPB MR1001 |
29 |
31 |
14 |
20 |
16.8 |
| RPB MR1002 |
35 |
31 |
19 |
24 |
16.8 |
| RPB MR1003 |
40 |
34 |
24 |
27 |
16.8 |
| RPB MR1201 |
29 |
31.8 |
14 |
20 |
19.8 |
| RPB MR1202 |
35 |
34 |
19 |
24 |
19.8 |
| RPB MR1203 |
40 |
35.8 |
24 |
27 |
19.8 |
| RPB MR1602 |
35 |
34.8 |
19 |
24 |
23.8 |
| RPB MR1603 |
40 |
36.6 |
24 |
27 |
23.8 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
