Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPT |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPY MR0400 |
R 1/8 |
4 |
|
| RPY MR0401 |
R 1/4 |
4 |
|
| RPY MR0500 |
R 1/8 |
5 |
|
| RPY MR0501 |
R 1/4 |
5 |
|
| RPY MR0502 |
R 3/8 |
5 |
|
| RPY MR0503 |
R 1/2 |
5 |
|
| RPY MR0600 |
R 1/8 |
6 |
|
| RPY MR0601 |
R 1/4 |
6 |
|
| RPY MR0602 |
R 3/8 |
6 |
|
| RPY MR0603 |
R 1/2 |
6 |
|
| RPY MR0800 |
R 1/8 |
8 |
|
| RPY MR0801 |
R 1/4 |
8 |
|
| RPY MR0802 |
R 3/8 |
8 |
|
| RPY MR0803 |
R 1/2 |
8 |
|
| RPY MR1000 |
R 1/8 |
10 |
|
| RPY MR1001 |
R 1/4 |
10 |
|
| RPY MR1002 |
R 3/8 |
10 |
|
| RPY MR1003 |
R 1/2 |
10 |
|
| RPY MR1201 |
R 1/4 |
12 |
|
| RPY MR1202 |
R 3/8 |
12 |
|
| RPY MR1203 |
R 1/2 |
12 |
|
| RPY MR1402 |
R 3/8 |
14 |
|
| RPY MR1403 |
R 1/2 |
14 |
|
| RPY MR1602 |
R 3/8 |
16 |
|
| RPY MR1603 |
R 1/2 |
16 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
| RPY MR0400 |
41.5 |
20 |
10 |
34 |
| RPY MR0401 |
43 |
20 |
14 |
34 |
| RPY MR0500 |
44 |
25.6 |
12 |
36.5 |
| RPY MR0501 |
45.5 |
25.6 |
14 |
36.5 |
| RPY MR0502 |
48 |
25.6 |
17 |
37 |
| RPY MR0503 |
50.5 |
25.6 |
21 |
37.5 |
| RPY MR0600 |
44 |
25.6 |
12 |
36.5 |
| RPY MR0601 |
45.5 |
25.6 |
14 |
36.5 |
| RPY MR0602 |
48 |
25.6 |
17 |
37 |
| RPY MR0603 |
50.5 |
25.6 |
21 |
37.5 |
| RPY MR0800 |
44.3 |
27.6 |
14 |
36.8 |
| RPY MR0801 |
45.8 |
27.6 |
14 |
36.8 |
| RPY MR0802 |
48.3 |
27.6 |
17 |
37.3 |
| RPY MR0803 |
50.8 |
27.6 |
21 |
37.8 |
| RPY MR1000 |
56.1 |
33.6 |
17 |
48.6 |
| RPY MR1001 |
57.6 |
33.6 |
17 |
48.6 |
| RPY MR1002 |
59.6 |
32.6 |
17 |
48.6 |
| RPY MR1003 |
62.1 |
33.6 |
21 |
49.1 |
| RPY MR1201 |
60.8 |
39.6 |
19 |
51.8 |
| RPY MR1202 |
63.3 |
39.6 |
19 |
52.3 |
| RPY MR1203 |
65.3 |
39.6 |
21 |
52.3 |
| RPY MR1402 |
64.8 |
45.4 |
22 |
53.8 |
| RPY MR1403 |
66.8 |
45.4 |
22 |
53.8 |
| RPY MR1602 |
66.5 |
47.6 |
24 |
55.5 |
| RPY MR1603 |
68.5 |
47.6 |
24 |
55.5 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
