Für Rohr mit Außen-Ø (mm)
4
Betriebsdruck
0 bis 10 bar
Temperatur
0°C bis + 60°C
Werkstoff
Polymer und Messing vernickelt
Beschreibung
| Artikelnummer |
AG BSPP |
Für Rohr mit Außen-Ø (mm) |
3D |
| RPY MG0400 |
G 1/8 |
4 |
|
| RPY MG0401 |
G 1/4 |
4 |
|
| RPY MG0500 |
G 1/8 |
5 |
|
| RPY MG0501 |
G 1/4 |
5 |
|
| RPY MG0502 |
G 3/8 |
5 |
|
| RPY MG0503 |
G 1/2 |
5 |
|
| RPY MG0600 |
G 1/8 |
6 |
|
| RPY MG0601 |
G 1/4 |
6 |
|
| RPY MG0602 |
G 3/8 |
6 |
|
| RPY MG0603 |
G 1/2 |
6 |
|
| RPY MG0800 |
G 1/8 |
8 |
|
| RPY MG0801 |
G 1/4 |
8 |
|
| RPY MG0802 |
G 3/8 |
8 |
|
| RPY MG0803 |
G 1/2 |
8 |
|
| RPY MG1000 |
G 1/8 |
10 |
|
| RPY MG1001 |
G 1/4 |
10 |
|
| RPY MG1002 |
G 3/8 |
10 |
|
| RPY MG1003 |
G 1/2 |
10 |
|
| RPY MG1201 |
G 1/4 |
12 |
|
| RPY MG1202 |
G 3/8 |
12 |
|
| RPY MG1203 |
G 1/2 |
12 |
|
| RPY MG1402 |
G 3/8 |
14 |
|
| RPY MG1403 |
G 1/2 |
14 |
|
| RPY MG1602 |
G 3/8 |
16 |
|
| RPY MG1603 |
G 1/2 |
16 |
|
Abmessungen
| Artikelnummer |
A mm |
B mm |
C mm |
D mm |
| RPY MG0400 |
40.5 |
20 |
12 |
33 |
| RPY MG0401 |
41 |
20 |
14 |
32 |
| RPY MG0500 |
43.5 |
25.6 |
12 |
36 |
| RPY MG0501 |
44 |
25.6 |
14 |
35 |
| RPY MG0502 |
45.5 |
25.6 |
17 |
34.5 |
| RPY MG0503 |
46.5 |
25.6 |
21 |
33.5 |
| RPY MG0600 |
43.5 |
25.6 |
12 |
36 |
| RPY MG0601 |
44 |
25.6 |
14 |
35 |
| RPY MG0602 |
45.5 |
25.6 |
17 |
34.5 |
| RPY MG0603 |
46.5 |
25.6 |
21 |
33.5 |
| RPY MG0800 |
45.3 |
27.6 |
14 |
37.8 |
| RPY MG0801 |
45.3 |
27.6 |
14 |
36.3 |
| RPY MG0802 |
46.8 |
27.6 |
17 |
35.8 |
| RPY MG0803 |
47.8 |
27.6 |
21 |
34.8 |
| RPY MG1000 |
57.3 |
33.6 |
17 |
49.8 |
| RPY MG1001 |
57.8 |
33.6 |
17 |
48.8 |
| RPY MG1002 |
57.8 |
32.6 |
17 |
46.8 |
| RPY MG1003 |
58.8 |
33.6 |
21 |
45.8 |
| RPY MG1201 |
60.5 |
39.6 |
19 |
51.5 |
| RPY MG1202 |
60 |
39.6 |
19 |
49 |
| RPY MG1203 |
61.5 |
39.6 |
21 |
48.5 |
| RPY MG1402 |
61.6 |
45.4 |
22 |
50.6 |
| RPY MG1403 |
63.5 |
45.4 |
24 |
50.5 |
| RPY MG1602 |
64.3 |
47.6 |
24 |
53.3 |
| RPY MG1603 |
61.8 |
47.6 |
24 |
48.8 |
Angaben zur Produktsicherheit
Herstellerinformationen:
Prevost SAS
rue du Pré Faucon 15
Auvergne-Rhône-Alpes
Annecy-le-Vieux, Frankreich, 74942
sales@prevost.eu
https://www.prevost.de/
| Produkteigenschaft |
Wert |
| Inhalt: |
1,00 Stück
|
